Product Introduction:
Carbon fiber filter element is not only has the inherent characteristics of carbon material, but also has the softness and workability of textile fiber, is a new generation of adsorption material, carbon fiber filter element more than 80% of the carbon atoms are located on the internal and external surface, built into a unique adsorption structure, known as superficial solid.
Carbon fiber filter is composed of cellulose and activated carbon powder composite depth filter, combined with the dual function of activated carbon adsorption of the filter material structure, the outer column of the filter is a precision fiber filter material coated with inner lining, supplemented with activated carbon fiber cloth around forming; When the liquid flows through the filter material, the outer layer of the deep fiber filter material structure can block pollution particles, the activated carbon in the filter cloth can remove the odor, odor, sediment, pigment, volatile organic compounds (VOC) and organic chemicals in the filtrate; Filter material innermost layer of fiber filter material, can prevent carbon particles and fine pollutants from flowing out, can provide filtrate final quality assurance and complete filtration treatment.
Main performance:
1. High filtration accuracy, small pressure difference, large flow, large sewage capacity, long service life;
2. The filter aperture is small inside and large outside, with good deep filtration effect;
3. The filter element is made of different materials to ensure the requirements of various liquid filtration and achieve the best filtration effect.
Main technical performance indicators:
1, filtration accuracy: 1μm-40μm;
2, filter outer diameter: φ60mm;
3, filter inner diameter: φ30mm;
4, active carbon effective carbon content in each 200 grams, can handle 200 liters of plating solution;
5, filter length: 10 ", 20 ", 30 ", 40"
6, high pressure: ≤ 0.5mpa; Maximum pressure drop: 0.2mpa
Product application field:
1. Filtered water: such as medium and large ultrapure water system pre-filtration treatment, beverage industry water pre-filtration treatment;
2, food industry filtration: such as cooking oil, vegetable oil filtration, syrup, chocolate and other kinds of slurry filtration;
3, chemical industry filtration: such as electroplating liquid filtration, paint, oil, paint filtration, mechanical oil, cutting oil, heavy oil, fuel oil filtration, high viscosity resin, oil filtration, pharmaceutical filtration;
Field of Application:
Carbon fiber filter applications: low liquid filter low surface treatment, electroplating solution of low solution filter "photographic development of grease removal with aromatic free fluorine, volatile organic compounds in the solution to remove low filtration treatment of drinking water, RO pure water machine low odor, odor, the removal of organic pigment's removal of organic chemistry in the solution
